Product Description
The Mallaghan CT4000 / CCT4000 are sophisticated Catering / Cabin Cleaning Trucks utilised for the efficient transportation of catering equipment, food supplies and cleaning equipment. Assembled on a truck mounted chassis with lifting van body and fully insulated GRP panels. Service height is up to 4.2 m / 165 inches.
Key Features
Van Body Height Adjustable (Raise/Lower)
Extendable Platform
Insulated Van Body
Roller Shutter Doors Front and Rear of Van Body
Dual Emengency Operation (Manual/Electric)
Fully IATA Compliant
Characteristics
Model:
CT4000/CCT4000
Sill Heights:
1300 mm (51 Inches) – 4200 mm (165 Inches)
Capacity:
1000kg (2200Ib) – 2000kg (4400Ib)
Chassis:
Standard Commercial Chassis (MAN, Ford, Isuzu, Volvo etc)
Platform:
Available in full or half width transversing option
Hydraulics:
Mallaghan scissors with built in hydraulic cylinders & hydraulic chassis stabilisers
Van Body:
Insulated GRP panels, 33mm (1.3 Inches) – 100mm (4 Inches)
Electric System:
12v / 24v relay or PLC computer
Typical Options:
- Tail-lift
- Refrigeration
- CAS (Controlled Approach System AHM 913)
- EN Compliant Safety Gate System
- Half cab (for lower sill height)
